19 inch Elevator Digital Signage LCD Advertising Screen 16:9 1G rAM Intelligent
Product Details:
| Place of Origin: | China |
| Brand Name: | ADKIOSK |
| Certification: | CE,FCC,ROHS, CB ,ISO9000, CCC |
| Model Number: | SNT1903 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | outter paper box, middle wooden box and inner foam |
| Delivery Time: | 5-8days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000pcs/month |
|
Detail Information |
|||
| Product Name: | Elevator Digital Signage | Brightness: | 350-700cdm |
|---|---|---|---|
| Panel Size: | 19inch | Response Time: | 6ms |
| Application: | Elevator Digital Signage | Viewing Angle: | 178 /178 |
| Video Format: | MPG,PMP,VOB,MKV,3GP | ||
| High Light: | 19 inch Elevator Digital Signage,16:9 Elevator Digital Signage,1G LCD Advertising Screen |
||
Product Description
19 inch lcd advertising screen android digital signage content management system hardware for elevator
Android Version Advertising Player
----------------update ads/programs by software platform remotelly
Efficient,Fast, and Convenient
1. Using A20 multimedia HD network decoder chip,based on Android 4.2.2 above OS with 1GB DDR3 memory,8gb flash ROM.More standard and open than PC based platform.
2. Support web/flash player,support two display modes while boot up:vertical and horizontal screen.
3. Support LVDS/HDMI/VGA/AV output power switch freely with 1080p point to point output. Support the printer device to output
4. Support multi-language,time setting,rolling text,clock and weather display.
5. Support any split-screen,multi-window display,different content in different windows.
6. Support remote reboot,remote shutdown,remote screenshot
7. B/S architechture, a strong background server management software support,you can set up online advertising machine parameters,create playlists issued online,real time/timing download programs from the servers and automatically play .
8. Support powerful network:network/wifi/4g
| Name18.5 | 19" lcd screen kiosk | ||
| Panel parameter | Size | 19inch LED screen | |
| Resolution | 136*768 | ||
| Brightness | 300cd/m*2 | ||
| Color | 16.7M | ||
| Aspect ratio | 16:9 | ||
| Response time | 6.5MS | ||
| Contrast | 4000:1 | ||
| View angle | 178°/168°(H/V) | ||
| Standard Specification | CPU | rk3288 | |
| Mainboard | rk3288 | ||
| ram | 1G | ||
| rom | 8GB | ||
| PC I/O Connectors | USB 3.0, 2*PS/2,1 * RJ45, 1 * Line-in, 1 * Earphone, 1 * Microphone, 1*LVDS |
||
| Network | built-in Realtek RTL8103EL | ||
| Audio | built-in HD audio 8(Realtek ALC888) audio system | ||
| speaker | 5W * 2 | ||
| wifi | yes | ||
| Environment | Operating Temperature :0°C to 40°C Storage Temperature :-20°C to 60°C Humidity:20%-80% RH at 40°C, |
||
| System Power Supply | AC 110V~240V,50/60HZ | ||
| Power cord | Yes | ||
| Case | Cold rolled steel with powder coating+ toughened glass surface | ||
| Standard operation software |
free
|
||
| Indoor Digital Display Features |
|
1. Only professional / commercialgrade A+ are used for our products.High brightness and contrast ratios are the key in delivering great visible advertising.
|
| 2. By using the visual extension technology ( S-PVA )it will give an easy 178 degrees viewing angle.No deformed pictures and no color distortion,perfect viewing. |
| 3. With a fast 5ms response time, blur, ghosting and distortion will be eliminated, giving way to a perfect dynamic picture . |
| 4. Easy upgradable options available; Android,Windows and network. |
| 5. Full metal shielding structure will prevent any exterior electromagnetic interference. |
| 6. Units are equipped with high quality digital audio outputs.Equipped with 3D reduction technology. |
| 7.Intelligent temperature control system will regulate and protect the equipment.Keeping the unit performance at peak level. |
How to use our Anroid network advertising player:
- Insert the USB dongle to PC to authorize this PC to install this software.Please close the firewall and some anti-virus software before install our signage software.
- Connect the mouse with the player, to roll down the mouse to find register, then you can input the IP address of your server.
- If all players in one narrow network, you can just use any PCs to be server
If players in different place, you need use the server with public IP, and all players can be connected with the server via public IP address - Then you control the players by the software on PC.
